11
Specifications
Storage Humidity (type tested) 90% R.H. (non-condensing) at +65
°
C (+149
°
F),
24 hrs
Shock (type tested) 30 g (half sine), 11 msec pulse
Vibration (type tested) Random, 0.21g rms, 5 to 500 Hz, 10 minutes per
axis
Sine, 0.5g (0 to peak), 5 to 500 Hz, 1 octave/min
Weight 200 g (7 oz) max
Dimensions (excludes power cable)
Height
Weight
Length 34 mm (1.34 in.)
38 mm (1.50 in.)
61 mm (2.4 in.)
Power Cable Length 200 mm (7.9 in.) from connector tip to N1022A
body
Table 3. Performance Specifications (1 of 2)
Frequency Range (Characteristic) 0 - 18 GHz
Power Input +17V 225 mA
–17V 225 mA
Output Voltage +12V ±5%
–12V ±5%
V prog ±5%
–V prog ±5%
Output Current 0 - 200 mA (+12V)
0 - 200 mA (–12V)
0 - 200 mA (V prog)
0 - 200 mA (–V prog)
≤
200 mA combined current: +12V and V prog
≤
200 mA combined current: –12V and –V prog
Probe Compatibility* Compatible with all Infiniimax active probes,
such as the 1131A/1132A/1134A and other
active probes such as the 1152A/1156A/1157A/
1158A.
Table 2. Environmental Specifications (2 of 2)
