Page 4
Figure 2
Bolt holes for installers' ease of
installation. Use appropriate pair of bolts
.
1 3/4" Typical
4" copper clad strap mounts
under the aluminum backplane.
(Aluminum backplane is tin-plated
for dissimilar metal reasons and
corrosion resistance)
(1/2" / 13 x 1" Bolts - Qty 2)
Ground Strap Attachment
