SERIES 2800 2800_IOM_REVA_1112
2800 IOM information present on control valve.doc
INFORMATION PRESENT ON CONTROL VALVE Series 2800
Part Number & Serial Number
Information
Symbol(s) Location Notes
Part number
(Configuration)
P/N
On actuator
•
On Actuator Nameplate attached to leg(s) of actuator.
Serial number
S/N
On actuator
and
valve body
•
On Actuator Nameplate attached to leg(s) of actuator.
•
Number only stamped on valve body end connection (2800).*
* Number stamped using approximately 1/8 inch tall characters
Flow Direction(s)
Information
Symbol(s) Location Notes
Flow direction
through valve
On valve
body
•
On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections (2800 S/S valves ½ thru 1 inch except 1 inch S/S 2832).
•
Arrow cast on valve body between the end connections (2800 S/S 2-way 1-1/4 thru 2
inch).
Inlet location
INLET
On valve
body
•
Stamped on valve body inlet end connection (2-way 2800 bronze valves ½ thru 2 inch
& S/S valves 1-1/4 thru 2 inch).
Port locations
for 3-way valves
U upper
port,
L lower port,
C common
port
On valve
body
•
U, L, & C stamped on valve body end connections (3-way 2800 bronze valves ½ thru
2 inch & 3-way 2800 S/S valves 1-1/4 thru 2 inch & 1 inch S/S 2832).
Input Signal & Supply
Information
Symbol(s) Location Notes
Input signal
SIG
On actuator
•
On Actuator Nameplate attached to leg(s) of actuator.
Supply pressure
SUP or
SUPPLY
On actuator
•
On Actuator Nameplate attached to leg(s) of actuator.
Valve Attributes
Information
Symbol(s) Location Notes
Maximum
temperature rating
of valve body
TMAX or
Tmax
On actuator
and
valve body
•
On Actuator Nameplate attached to leg(s) of actuator.
•
On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-
1/4 thru 2 inch, & 1 inch S/S 2832).
•
On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch
except 1 inch S/S 2832).
Trim Cv
(Flow coefficient)
Cv
On valve
body
•
On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-
1/4 thru 2 inch, & 1 inch S/S 2832).
•
On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch
except 1 inch S/S 2832).
Trim style
(Characteristic)
CHAR
On valve
body
•
On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-
1/4 thru 2 inch, & 1 inch S/S 2832).
Trim material
TRIM MATL
On valve
body
•
On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-
1/4 thru 2 inch, & 1 inch S/S 2832).
Valve size
SIZE
On valve
body
•
On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch
except 1 inch S/S 2832).
Valve body material
On valve
body
•
If CF8M is cast on the valve the valve body material is 316 stainless steel.
InFOrmatIOn PrEsEnt On cOntrOL vaLvE sErIEs 2800
