17
SERIES 2800 2800_IOM_REVA_1112
PARTS KITS
ADDITIONAL BONNET SUBASSEMBLY PARTS IN REPACK/INSPECTION KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE T V-RING
SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
8 1 O-RING RETAINER 10 1 BONNET BEARING
9 1 O-RING 11 1 BONNET
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE T V-RING
SEE DWG C3760953
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 BONNET 3 1 O-RING
2 1 BONNET BEARING 4 1 O-RING RETAINER
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & TYPE G GRAPHITE
SEE DWG C3769952
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
6 1 BONNET 7 1 BONNET BEARING
FOR 28N MODELS WITH BODY MATERIAL F CF8M & TYPE G GRAPHITE
SEE DWG C3760955
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 BONNET 2 1 BONNET BEARING
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE V VACUUM SERVICE
SEE DWG C3761956
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
9 1 O-RING RETAINER 11 1 BONNET BEARING
10 1 O-RING 12 1 BONNET
FOR 28N MODELS WITH BODY MATERIAL F CF8M & TYPE V VACUUM SERVICE
SEE DWG C3760961
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
9 1 O-RING RETAINER 11 1 BONNET BEARING
10 1 O-RING 12 1 BONNET
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE L LIP PACKING
SEE DWG C3769956
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
6 1 BONNET 7 1 BONNET BEARING
