313 OvERFLOw TRAP PARTS KiTS
(PROviDE OvERFLOw TRAP SERiAL NUmBER TO GET KiT PART NUmBERS)
Three different parts kits are available. The inspection kit allows for the overflow trap to opened so its internal
parts may be inspected. The float ball kit allows for the float ball to be replaced. The internal vba kit allows for
the entire internal valve body assembly, minus the float ball, to be replaced. The internal vba kit is preset at the
factory to provide the correct water level in the float chamber.
313 iNSPECTiON KiT - SEE DwG 03130611101
itEm Qty DEScriPtiON itEm Qty DEScriPtiON
19 1 INNER VALVE BODY GASKET 23 1 END COVER GASKET
313 FLOAT BALL KiT - SEE DwG 03130611101
itEm Qty DEScriPtiON itEm Qty DEScriPtiON
4 1 FLOAT BALL 23 1 END COVER GASKET
19 1 INNER VALVE BODY GASKET
313 iNTERNAL vBA KiT - SEE DwG 03130611101
itEm Qty DEScriPtiON itEm Qty DEScriPtiON
1 2 CAPSCREW 12 1 JAMNUT
2 A / R WASHER 13 1 LEVER BRACKET BASE
3 A / R CAPSCREW 14 1 INNER VALVE BODY COVER
5 1 FLOAT LEVER 15 1 INNER VALVE BODY
6 3 CLEVIS PIN 16 1 PILOT SUBASSEMBLY
7 3 COTTER PIN 17 1 STEM GUIDE
8 1 LEVER BRACKET 18 3 CAPSCREW
9 1 FULCRUM LINK 19 1 INNER VALVE BODY GASKET
10 1 CLEVIS 20 1 PISTON
11 1 JAMNUT 23 1 END COVER GASKET
