5.2 Thermocouple Simulation
The 10mV range of the 1030 is ideal for simulation of all types of thermocouple. Just
find the voltage required from the British Standard tables, (common values given
below), and set up on the 1030’s dial. Do not forget to allow for the Cold Junction
temperature.
Thermocouples Temperature tables ITS90.
Temp °C
-
100°C -50°C -25°C 0°C 25°C 37°C 50°C 75°C 100°C
T/C
TYPE mV mV mV mV mV mV mV mV mV
Type K NiCr/NiAl -3.554 -1.889 -0.968 0.000 1.000 1.489 2.023 3.059 4.096
Type T Cu/Con -3.379 -1.819 -0.940 0.000 0.992 1.486 2.036 3.132 4.279
Type J Fe/Con - - - 0.000 1.277 1.902 2.585 3.918 5.269
Type R Pt13%RH/Pt - - -0.123 0.000 0.141 0.214 0.296 0.466 0.647
Type B Pt30%RH / Pt6%RH - - - 0.000 -0.002 -0.002 0.002 0.014 0.033
Type S Pt10%RH/Pt - - -0.127 0.000 0.143 0.216 0.299 0.467 0.646
Type N NiCr/NiSi - - -0.646 0.000 0.659 0.983 1.340 2.045 2.774
Temp °C 150°C 200°C 300°C 400°C 500°C 600°C 700°C 800°C 900°C
T/C
TYPE mV mV mV mV mV mV mV mV mV
Type K NiCr/NiAl 6.138 8.138 12.209 16.397 20.644 24.905 29.129 33.275 37.326
Type T Cu/Con 6.704 9.288 14.862 20.872 - - - - -
Type J Fe/Con 8.010 10.779 16.327 21.848 27.393 33.102 39.132 45.494 51.877
Type R Pt/Pt 13%RH 1.041 1.469 2.401 3.408 4.471 5.583 6.743 7.950 9.205
Type B Pt30%RH / Pt6%RH 0.092 0.178 0.431 0.787 1.242 1.792 2.431 3.154 3.957
Type S Pt10%RH/Pt 1.029 1.441 2.323 3.259 4.233 5.239 6.275 7.345 8.449
Type N NiCr/NiSi 4.302 5.913 9.341 12.974 16.748 20.613 24.527 28.455 32.371
Temp °C 1000°C 1100°C 1200°C 1300°C 1400°C 1500°C 1600°C 1700°C 1800°C
T/C
TYPE mV mV mV mV mV mV mV mV mV
Type K NiCr/NiAl 41.276 45.119 48.838 52.410 - - - - -
Type T Cu/Con - - - - - - - - -
Type J Fe/Con 57.953 63.792 69.553 - - - - - -
Type R Pt/Pt 13%RH 10.506 11.850 13.228 14.629 16.040 17.451 18.849 20.222
Type B Pt30%RH / Pt6%RH 4.834 5.780 6.786 7.848 8.956 10.099 11.263 12.433 13.591
Type S Pt10%RH/Pt 9.587 10.757 11.951 13.159 14.373 15.582 16.777 17.947 -
Type N NiCr/NiSi 36.256 40.087 43.846 47.513 - - - - -
