TC-3000G SPECIFICATION
Temperature
Gradient range 20°C to 80°C
Maximum gradient 15°C
Minimum gradient 1°C
Temperature range 4°C to 99°C
Temperature set point precision 0.1°C
Block uniformity (over full range) ± 0.2°C
Temperature accuracy ± 0.2°C
Pre-run sample cooling Yes
End of program cooling below ambient Yes
Heating/Cooling Rate
Heating rate, between 55°C and 90°C
on a 50°C to 95°C step:
0.2 ml micro tubes 3.3°C/sec
0.5 ml micro tubes 3.3°C/sec
Cooling rate, between 90°C and 55°C
on a 95°C to 50°C step:
0.2 ml micro tubes 2.0°C/sec
0.5 ml micro tubes 2.0°C/sec
Heated Lid
Adjustable heated lid Yes
Heated lid enable/disable Yes
Selectable heated lid temperature 100°C to 115°C
Over-temperature cut-out Fixed at 145°C
Temperature sensor Thermistor
Heater type Etched foil
Heater power 33W
Warm up time 4 min approximately
(ambient to 105°C)
The heated lid will only come on
if the set temperature is above 35°C
