D B - 3 D w i t h R S 2 3 2 O P E R A T O R ’ S M A N U A L
P A G E 19
When you Switch On
When you first switch on, the display will show the edition of the software which
your unit uses. For example software issue "1" would be shown as follows:
It will display this for 1 second, then the actual temperature of the platten will
be indicated.
The Front Panel Controls
The front panel controls consist of three buttons for controlling the display, a
four digit LED display and three indicators.
The SET temperature Button
The SET temperature button displays the set temperature when pressed.
The UP ARROW Button
When the SET temperature button is held down and the UP ARROW button
is pressed, the set temperature is increased.
