3-1

Section 3 - SPECIFICATIONS

Model Number

*

La

mp Li

g

h

ted Length,

Inches (mm

)

La

mp Wat

tage

La

mp T

y

pe

Lamp Par

t Number

La

mp

Ra

ted

Vo

lt

ag

e

Wa

tt

age

He

at

er, kW

**

*

W

a

ter Flow GPM

(LPM

)

Pressure Dr

op

Through

Heater @

Required

Wat

er Flow

, psi +/-

5psi

Total Weight,

Poun

ds

(kg

)

4069-12R-10L-12kW-240V 10 (254) 1000 QIH240-1000RI2

103390-003 240

12.0

1.2 (4.5)

10

85 (39)

4069-12R-10L-12kW-480V 10 (254) 1000 QIH240-1000RI2

103390-003 240

12.0

1.2 (4.5)

10

85 (39)

4069-12R-10L-24kW-240V 10 (254) 2000 QIH240-2000RI2

103390-004 240

24.0

2.3 (8.6)

22

85 (39)

4069-12R-10L-24kW-480V 10 (254) 2000 QIH240-2000RI2

103390-004 240

24.0

2.3 (8.6)

22

85 (39)

4069-12R-16L-19kW-240V 16 (406) 1600 QIH240-1600RI2

103390-005 240

19.2

1.8 (6.9)

16

95 (43)

4069-12R-16L-19kW-480V 16 (406) 1600 QIH240-1600RI2

103390-005 240

19.2

1.8 (6.9)

16

95 (43)

4069-12R-25L-30kW-480V 25 (635) 2500 QIH480-2500RI2

103390-007 480

30.0

1.4 (5.3)

**

31 124

(56)

4069-12R-38L-46kW-480V 38 (965) 3800 QIH480-3800RI2

103390-010 480

45.6

2.1 (8.0)

**

63 155

(70)

4069-18R-10L-18kW-240V

10 (254) 1000 QIH240-1000RI2

103390-003 240

18.0

1.7 (6.5)

15

112 (51)

4069-18R-10L-18kW-480V

10 (254) 1000 QIH240-1000RI2

103390-003 240

18.0

1.7 (6.5)

15

112 (51)

4069-18R-10L-36kW-480V

10 (254) 2000 QIH240-2000RI2

103390-004 240

36.0

3.3 (12.7)

42

112 (51)

4069-18R-16L-29kW-240V

16 (406) 1600 QIH240-1600RI2

103390-005 240

28.8

2.7 (10.2)

29

140 (64)

4069-18R-16L-29kW-480V

16 (406) 1600 QIH240-1600RI2

103390-005 240

28.8

2.7 (10.2)

29

140 (64)

4069-18R-25L-45kW-480V 25 (635) 2500 QIH480-2500RI2

103390-007 480

45.0

2.1 (7.9)

**

61 177

(80)

4069-18R-38L-68kW-480V 38 (965) 3800 QIH480-3800RI2

103390-010 480

68.4 3.1 (11.9)

**

37 228

(104)

*

Recommended maximum product diameter of 12-reflector models is two inches. Recommended maximum product diameter of 18-reflector model is

four inches.

**

Stated flow rates are for each of two flow paths

***

Maximum inlet-water temperature not to exceed 100

°F (37°C)
