If “Review” was selected, the test points would be displayed.
Press the INC/DEC keys to scroll through additional points. Press ENT or
CE to return to the previous menu.
Clear All Data allows “As Found” and “As Left” data previously stored to
be cleared. This option is only allowed if enabled by the Calibration
System. If this option is not enabled, the display will not have Clear All
Data as an option beneath the REVIEW and TEST options.
If AUTO was pressed to start the “As Found” test, the display will
indicate:
Once the test is completed, the display will indicate “Test Complete” on
the top line, whether the unit passed or failed on the second line and,
give the operator four choices on lines three and four - Review, Adjust,
Retest, Done. Selecting “Review” allows the operator to review the test
data, selecting “Retest” allows the test to be run again, selecting
“Done” takes the calibrator to the final sequence, selecting “Adjust”
allows the operator to adjust the instrument under test.
Selecting “Adjust” allows the operator to perform a normal calibration
procedure on the instrument under test. Pressing the INC/DEC key will
Operation
230/235 12
INPUT OUTPUT
+4.000 +10.000
+6.000 +20.000
+8.000 +30.000
MA mVOLTS
+4.000 +10.000
TESTING CALPT 01
AS FOUND
TEST COMPLETE
UNIT FAILED
REVIEW ADJUST
RETEST DONE
