Basic setting – KYORITSU 6315 Quick Manual User Manual
Page 38
KEW6315
Setting （SETUP）
KEW6315
- 36 -
Basic setting
Setting item
Details of setting
Wiring
(1)1P2W×1
(2)1P2W×2
(3)1P2W×3
(4)1P2W×4
(5)1P3W×1
(6)1P3W×2
(7)3P3W×1
(8)3P3W×2
(9)3P3W3A
(10)3P4W
* Current terminals that are not used in the selected wiring system can be used to
measure rms currents and harmonics.
Voltage range
600V/1000V
VT ratio
0.01-9999.99(1.00)
Nominal voltage
50V-600V(100V)
Clamp/ current range
8128:5/50A/AUTO
8127:10/100A/AUTO
8126:20/200A/AUTO
8125:50/500A/AUTO
8124/8130:100/1000A/AUTO
8129:300/1000/3000A
8141:
8142:
500mA/AUTO
8143:
8146:
8147:
1/10A/AUTO
8148:
CT ratio
0.01-9999.99(1.00)
DC range
100mV/1.000V/10V
Frequency
50Hz/60Hz
* Default values are highlighted in gray.
Power Clamp sensor
Leakage current Clamp sensor
