KYORITSU 5410 - Manual (Page 2)

Contents
1. Safety Warnings…………………………….…………... 1
2. Procedure of removing Cover………………………….… 3
2-1 Method of removing the Cover…………………….… 3
2-2 Method of storing the Cover……………………….…. 3
3. Feature….………………………..…………………….….. 4
4. Specification…………………………..…..…………….…. 5
5. Instrument Layout……………………………………….… 8
6. Measurement principle………………………………….... 10
7. Preparation……………………………………………….... 11
7-1 Connection of Test Leads………………………….…. 11
7-2 Setting of Measurement Range………………….... 11
7-3 Setting of IΔn……………………………………….….. 12
7-4 Setting of Test Polarity…………………………….….. 12
7-5 Backlight………………………………………………... 12
8. Measurements…………………………………………... 13
8-1 Connection………………………………………….…. 13
8-2 Voltage Measurement……………………………….... 13
8-3 RCD Test………………………………………..……... 14
8-4 Remote Test…………………………………...….…. 14
8-5 Operating time……………………………..……..…. 18
9. Battery Replacement………………………………….... 19
10. Strap Belt Assembly…………………………………..… 20
Symbols used on the instrument
CAT.II Primary electrical circuits of equipment connected to an AC
electrical outlet by a power cord
.
CAT.III Primary electrical circuits of the equipment connected
directly to the distribution panel, and feeders from the
distribution panel to outlets.
Protected throughout by DOUBLE INSULATION or
REINFORCED INSULATION
User must refer to the explanations in the instruction manual.
Earth Ground
