Device description
2.1 Scope of delivery
The following items are supplied with the device:
• Measuring device
• Hygienic adapter
• Product documentation
2.2 System description
Inputting physical quantities into an SPC or PLC or other computer and control systems requires
accurate and reliably working sensors. The sensor is a detecting element that converts physical
quantities, such as temperature, level, pressure, conductivity, turbidity and flow, into an
electrical signal. Locally further processed, usually by an integrated microcontroller, the
measuring signal can be transmitted by analogue (e.g. 4...20 mA loop). The LS 6600 is designed
to detect the level of liquids or for pump protecting purposes.
2.3 Nameplate
The important technical values are engraved on the device body.
INFORMATION!
Inspect the cartons carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Figure 2-1: Example of engraved technical values
1 Device type
2 Electrical data for input
3 Electrical data for output
4 Operating temperture limits
