Programming
F232224 18
NOTE: ON appears ONLY where motor control
outputs are on (otherwise they are off). Outputs
referenced are on control unit fuse board. Outputs
are as labeled on the fuse board.
NA – Not Applicable
NOTE: For variable-speed machines smaller than
C80, SPn1 and SPn2 are not the same speed.
Table 5 (Continued)
Control Test
Spin coast delay Displays “SdLY”, then to normal stop routine.
Outputs: All off
Stop routine Display shows “StoP”, agitates briefly, shows “donE”, and allows door to unlock.
Table 5
Motor Speed Chart
Variable-Speed Motor Control
Outputs
Fixed-Speed and
2 Speed Motor
Outputs
STF STR RH RM RL Fwd Rev Spin
Motor off (no rotation)
Wash speed forward ON ON ON
Wash speed reverse ON ON ON
Distribution (variable-speed ONLY) ON ON NA NA NA
Lowest spin (low spin speed “SPn1” for
variable-speed) ON ON ON ON
Medium spin (“SPn2” – variable-speed ONLY) ON ON ON NA NA NA
Highest spin (“SPn3” – variable-speed ONLY) ON ON ON NA NA NA
