Programming
13 F232224
To Edit an Entire Wash Cycle
Formula
1. Enter PROGRAM Mode. Refer to Entering
Program Mode section.
2. Press the ∧ keypad until display shows “CY01”.
3. Select the cycle by pressing the desired cycle
number.
4. Press START keypad to edit the cycle.
Agitation for the Cycle
5. With display showing “CYXX” (xx = cycle
number), press the START keypad. Display
shows “AG1”, “AG2”, “AG3” or “AG4”. Refer to
Table 4 for a description on Agitation.
Wash 1 – Wash 5
NOTE: Programming a time other than “00” for
Wash 1 will make the WASH indicator LED light
while this step is running, but NOT in PROGRAM
Mode.
6. The main display shows “USH1” indicating you
are in the Wash segment (number will reflect
selected Wash segment 1-5).
7. Press START keypad. Display shows agitation
time during the step: “00” (skips segment) or
2-30 minutes. This is the time after the fill and
before the drain and does not include spin time or
time to first reach a programmed temperature (if
your machine is configured for heat).
8. Press the ∧ or ∨ keypad to alter the selection, or
the START keypad to continue.
9. Display shows “CFIL”, “HFIL”, “bFIL” (for
cold, hot, or warm [both]) or “AFIL”.
10. Press the ∧ or ∨ keypad to alter the selection, or
the START keypad to continue.
NOTE: Auxiliary Fill (“AFIL”) possible only if
configured for “AFIL” in SETUP Mode. If
configured, auxiliary fills can be programmed to
low, medium or high water level in a cycle step.
11. Display shows “LO”, “ n Ed”, or “HI” for low,
medium, or high water level, respectively.
12. Press the ∧ or ∨ keypad to alter the selection, or
the START keypad to continue.
13. Display shows “SUP0”, “SUP1”, “SUP2”,
“SUP3”, “SUP4”, “SUP5”, “SUP6” or “SUP7”.
Refer to Table 3 for operation of each supply
selection.
14. Press the ∧ or ∨ keypad to alter the selection, or
the START keypad to continue.
NOTE: “SUP5” and “SUP6” appear ONLY if
control is configured for “SUP5” in SETUP Mode.
If the alternate function is selected (“AFIL”), the
output will function as an additional fill valve
signal with a programmable water level. In this
case, the extra supply function would NOT be
available.
NOTE: If programmed for “SUP2”, the ADD
BLEACH indicator LED light turns on and the
buzzer sounds while supply 2 is on.
15. Display shows “bEEP” or “nobP”.
16. Press the ∧ or ∨ keypad to alter the selection or
START keypad to continue.
The leftmost supply compartment (as seen from front
of machine), which can be used for detergent, flushes
during fill cycles whether Supply 1 option is enabled
or disabled. When Supply 1 option is enabled, Supply
1 (S1) output energizes and is available for external
chemical supply if desired. The Supply 2 option
controls the middle compartment, which can be used
for bleach. Supply 3 and Supply 7 options control the
rightmost compartment, which can be used for fabric
softener. Supply 4, Supply 5 and Supply 6 options
control external chemical supplies, as desired. Refer to
Table 3 for operation of each supply selection.
NOTE: For additional assistance, refer to
installation instructions.
Display Meaning
AG1 18 seconds forward, 3 seconds pause, 18
seconds reverse, 3 seconds pause and repeat
for the programmed time
AG2 3 seconds forward, 27 seconds pause, 3
seconds reverse, 27 seconds pause and repeat
for the programmed time
AG3 10 seconds forward, 20 seconds pause, 10
seconds reverse, 20 seconds pause and repeat
for the programmed time
AG4 4 seconds forward, 56 seconds pause, 4
seconds reverse, 56 seconds pause and repeat
for the programmed time
Table 4
