Programming
17 F232224
Control Test
Warm fill to low water level Display flashes “bFIL”/“LO” (WASH LED on) with agitation, LOW water level dot on
when level reached, then to next step.
Outputs: Motor ON, Drain closed, hot fill on, cold fill on
Cold fill to medium water level Display flashes “CFIL”/“nEd” (WASH LED on) with agitation, MEDIUM water level dot
on when level reached, then to next step.
Outputs: Motor ON, Drain closed, cold fill on
Hot fill to high water level Display flashes “HFIL”/“HI” (WASH LED on) with agitation, HIGH water level dot on
when level reached, then to next step.
Outputs: Motor ON, Drain closed, hot fill on
Heat and Supply 1 on Display flashes “HEAt”/“SUP1” (WASH LED on) with agitation, Supply 1 is on for 5
seconds, then to next step.
Outputs: Motor ON, Drain closed, Supply 1 on, Heat on
Heat and Supply 2 on Display flashes “HEAt”/“SUP2” (BLEACH LED on) with agitation, Supply 2 is on for 5
seconds, then to next step.
Outputs: Motor ON, Drain closed, Supply 2 on, Heat on
Heat and Supply 3 on Display flashes “HEAt”/“SUP3” (RINSE LED on) with agitation, Supply 3 is on for 5
seconds, then to next step.
Outputs: Motor ON, Drain closed, Supply 3 on, Heat on
Supply 4 on Display shows “SUP4” (RINSE LED on) with agitation, Supply 4 is on for 5 seconds, then
to next step.
Outputs: Motor ON, Drain closed, Supply 4 on
Supply 5 or Auxilliary fill on Display shows “SUP5” or “AFIL” (RINSE LED on) with agitation, Supply 5 is on for 5
seconds, then to next step.
Outputs: Motor ON, Drain closed, Supply 5/Auxilliary fill on
Motor rotates slow wash reverse Display flashes “SLo”/“rEv” for 60 seconds, then to next step.
Outputs: Motor ON (slow reverse)
Motor rotates slow wash
forward Display flashes “SLo”/“For” for 60 seconds, then to next step.
Outputs: Motor ON (slow forward)
Motor rotates normal wash
reverse Display flashes “norn”/“rEv” for 60 seconds, then to next step.
Outputs: Motor ON (normal reverse)
Motor rotates normal wash
forward Display flashes “norn”/“For” for 60 seconds, then to next step.
Outputs: Motor ON (normal forward)
Drain and Distribution Display flashes “drai”/“For” until machine drains, then to next step.
Outputs: Motor ON (distribution), Drain opens in 15-27 seconds
Spin 1 Display shows “SPn1” (SPIN LED on) for 60 seconds, then to next step.
Outputs: Motor ON (Low Spin)
Spin 2 Display shows “SPn2” (SPIN LED on) for 60 seconds, then to next step.
Outputs: Motor ON (Medium Spin)
Spin 3 Display shows “SPn3” (SPIN LED on) for 60 seconds, then to next step.
Outputs: Motor ON (High Spin)
Table 5 (Continued)
