KROHNE OPTISOUND 3050C 4wire EN - Manual (Page 43)

45 m 30 m 15 m 3 m
90 mm
6 mm
-6 mm
-90 mm
30 mm
-60 mm
60 mm
-30 mm
Fig. 23: Accuracy OPTISOUND 3050 C version A
OPTISOUND 3050 C - 4 ... 20 mA/HART - four-wire 43
