CONNECTION OF SEPARATE SYSTEMS
3
17
OPTISONIC 3400
www.krohne.com 10/2013 - 7313222100 - AD CSA OPTISONIC 3400 -en- R01
Connection of flow sensor type Cryogenic and XXT
Figure 3-2: Connect the cables in the connection box of the flow sensor
Figure 3-3: Construction of field version
1 Signal converter
2 Open connection box
3 Tool for releasing connectors
4 Marking on cable
5 Insert cable(s) into terminal compartment
