6
MODBUS PROTOCOL
14
IFC 050
www.krohne.com 09/2012 - 4002202601 - AD Modbus IFC 050 R01 en
6.8.2 Process input filter and self test parameters
Modbus protocol
address Description and settings Converter Fct.
No. Type Number of
registers
1st 2nd
42000 2000 flow direction flow direction flow direction flow direction
0 = normal direction
1 = reverse direction
C1.2.2 byte 1
42001 2001 pulse filter pulse filter pulse filter pulse filter
0 = off
1 = on
2 = automatic
C1.2.4 byte 1
42002 2002 empty pipe empty pipe empty pipe empty pipe
0 = off
1 = conductivity
2 = empty pipe (S)
3 = empty pipe (F)
4 = empty pipe (I)
C1.3.1 byte 1
43000 3000 limitation low limitation low limitation low limitation low [m/s] C1.2.1 float 2
43002 3002 limitation high limitation high limitation high limitation high [m/s] C1.2.1 float 2
43004 3004 time constant time constant time constant time constant [s] C1.2.3 float 2
43006 3006 pulse width pulse width pulse width pulse width [s]
only if pulse filter is set to 1: on
C1.2.5 float 2
43008 3008 pulse limitation pulse limitation pulse limitation pulse limitation [m/s]
only if pulse filter is set to 1: on
C1.2.6 float 2
43010 3010 pulse width pulse width pulse width pulse width [s]
only if pulse filter is set to 2: automatic
C1.2.5 float 2
43012 3012 low flow cutoff value low flow cutoff value low flow cutoff value low flow cutoff value [m/s] C1.2.7 float 2
43014 3014 limit empty pipe limit empty pipe limit empty pipe limit empty pipe [S/m] C1.3.2 float 2
43016 3016 Zero point Zero point Zero point Zero point [m/s] C1.1.1 float 2
43018 3018 Electrode Factor EF Electrode Factor EF Electrode Factor EF Electrode Factor EF [m] C1.1.8 float 2
43020 3020 Conductivity Calpoint Conductivity Calpoint Conductivity Calpoint Conductivity Calpoint [S/m] C1.1.8 float 2
43022 3022 Conductivity Calpoint Conductivity Calpoint Conductivity Calpoint Conductivity Calpoint [S/m] C1.1.8 float 2
