2
228-1672 REV 2 072210
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
FIGURE 1. POWER SUPPLY MOUNTING
FIGURE 2. LOAD CONNECTIONS
3043386
300W
600W
1500W
NOTE:
MAINTAIN A 1.25 IN. [30 MM] DISTANCE
(2.0 IN. [50MM] FOR 600W) BETWEEN
VENTILATION HOLES, FAN SURFACE
AND SURROUNDING EQUIPMENT AND
INSTALL SO AS TO PROVIDE
ADEQUATE HEAT EXCHANGE TO
OUTSIDE AIR.
STANDARD MOUNTING
SIGNAL TERMINALS:
KEY:
AC INPUT TERMINALS:
DC OUTPUT TERMINALS/BUS: OR
