I N S T R U C T I O N S H E E T
RA 44
KEPCO
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
An ISO 9001 Company.
RA 44 RACK ADAPTER
DESCRIPTION (Refer to Fig. 1.)
The Kepco Model RA 44 RACK ADAPTER is designed for the installation of Kepco Power Assemblies into a stan-
dard 19-inch (482.6 mm) rack. The Rack Adapter occupies 5.064 inches (128.63 mm) of vertical space in the stan-
dard 19-inch equipment rack and is 16-inches (406.4 mm) deep.
The Rack Adapter may be mounted fixed or may be equipped with optional slides. The unit comes fitted with
bracket spacers (shim bars for equipment slides), four rubber feet, a “U” shaped removable cover with twelve
mounting screws, Rack Adapter handles and Mounting Ears. Rack Adapter, RA 44 was developed to provide
mounting space for a multitude of Kepco's linear and switching power supplies. The Rack Adapter may be
equipped with a variety of front panel and rear panel components to form a complete rack-mounted power assem-
bly designed by the user.
Details about all available power supplies, panel components and accessories to be used with RA 44 Rack
Adapter may be found in Kepco's Power Supplies Catalog, “Power Assemblies” Section. It is available from your
Kepco Representative, or directly from Kepco, lnc., 131-38 Sanford Avenue, Flushing, N.Y. 11355, USA.
Mechanical dimensions, material and finish of the Kepco Model RA 44 Rack Adapter are provided in Figure 2.
FIGURE 1. KEPCO MODEL RA 44 RACK ADAPTER
