I N S T R U C T I O N S H E E T
KEPCO
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
An ISO 9001 Company.
MA
100V
FAW/RKW
MOUNTING ADAPTER FAW/RKW 100V
DESCRIPTION. The RoHS-compliant Model MA FAW/RKW 100V Mounting Adapter includes an adapter plate and
mounting screws that allow a 100W RKW power supply to be easily substituted for a vertically-mounted 100W FAW
power supply. Mount the adapter plate to the RKW power supply using the screws provided (see Figure 1), then
install the adapter plate in place of the FAW power supply using the screws that previously secured the FAW power
supply.
FIGURE 1. ADAPTER PLATE INSTALLATION
