2
228-1689 REV 1 091713
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
DESCRIPTION. Five KLR Models and five KLR E-Series Models are available, as listed in Table 1.
The standard Models are GPIB and RS 232 compatible; the KLR E-Series Models (identified by the E
suffix) are GPIB and LAN (ethernet, LAN) compatible. The only difference between standard and E-
Series models is that LAN replaces the RS 232 interface on E-Series models. All models allow remote
analog programming as well as local control. For each model a multitude of limit models can be config-
ured. Limit models allow the unit to be configured to maximum settings below the rated voltage and/or
rated current. When a limit model is established the unit will not accept programming values above the
user-defined limits.
OPTIONS. The Rapid Output Discharge Circuit (RODC) option (suffix R) is available on all KLR mod-
els. This circuit rapidly discharges the output capacitance, thus significantly reducing response time to
reductions in output voltage (see KLR User Manual for details).
UNPACKING. This instrument has been thoroughly inspected and tested prior to packing and is
ready for operation. After careful unpacking, inspect for shipping damage before attempting to operate.
Perform the PRELIMINARY OPERATIONAL CHECK. If any indication of damage is found, file an imme-
diate claim with the responsible transport service.
EQUIPMENT SUPPLIED . See Table 2.
TABLE 1. MODEL PARAMETERS
Model number
Rated
Voltage
Range
Minimum
Programmable
current
Rated
Current
Range
Ripple and
noise
p-p
(1)
Efficiency
@230 Va-c
KLR 20-120
(2)
0-20V 1.5A 0-120A 100 mV 87%
KLR 40-60
(2)
0-40V 0.8A 0-60A 80 mV 88%
KLR 75-32
(2)
0-75V 0.4A 0-33.3A 80 mV 87%
KLR 150-16
(2)
0-150V 0.2A 0-16A 100 mV 88%
KLR 300-8
(2)
0-300V 0.1A 0-8A 150 mV 89%
(1) Bandwidth: 20MHz; low frequency ripple may be higher at loads less than 30 Watts.
(2) Specifications apply to both standard and E Series (Suffix E) models.
TABLE 2. EQUIPMENT SUPPLIED
ITEM PART NUMBER QUANTITY
Jumper (24 AWG or larger bus wire) for local sensing connections 172-0638 2
Analog I/O port mating connector 142-0528 1
Nut with captive lockwasher (on output studs of 20V and 40V models only) 102-0175 2
Quick Start Guide* 228-1689 1
* User Manual and Developer’s Guide are available as free downloads from:
www.kepcopower.com/support/opmanls.htm#klr
Drivers are available as free downloads from
www.kepcopower.com/drivers/drivers-dl3.htm#klr
