TABLE 2. GENERAL SPECIFICATIONS FOR TWO (2) IDENTICAL BOP 1000 WATT UNITS (PARALLEL)
SPECIFICATION RATING/DESCRIPTION CONDITION
INPUT CHARACTERISTICS
Current 176 Va-c 15.0A a-c maximum
264 Va-c 10A a-c maximum
Leakage current 7mA a-c 230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
d-c Output Range E
O Max
±6V d-c
I
O Max
±250A d-c
Closed Loop Gain Voltage Channel 0.6
Current Channel 25.0
Source/sink
adjustment range Voltage –6V to +6V
Current –250A to +250A
Programming
resolution / accuracy Voltage ±6mV
Current ±375mA
Voltage Limit ±6mV linearity ±120mV Full Scale tolerance
Current Limit ±375mA linearity ±2.75A Full Scale tolerance
Readback
resolution / accuracy Voltage Same as individual unit Independent readings for each unit
Current Same as individual unit Independent readings for each unit
Current stabilization in current mode
Source effect ±125mA Min - max input voltage
Load effect ±500mA 0 to 100% load current
Time effect (drift) ±125mA 0.5 through 24 hours
Temperature effect ±125mA / °C 0° to 50°C
Ripple and noise ±5Ap-p Includes switching noise.
Voltage stabilization in voltage mode Same as individual unit
Rise/Fall Time
Voltage 250 µ S/250 µ S
Nominal resistive load, measured from
10 to 90%, 0 to ±100% of rating
Current 1.5mS/1.5mS
Short circuit, measured from 10% to
90%, 0 to ±100% of rating
Frequency bandwidth
Voltage 2KHz
Nominal resistive load, E
OPK
= E
ONOM
,
I
OPK
= I
ONOM
@ 60Hz
Current 400Hz Short circuit, I
OPK
= I
ONOM
@ 60Hz
