FAN REPLACEMENT KIT
1. DESCRIPTION
This kit provides a fan assembly which replaces fan motor, Kepco part number 148-0026. The kit includes a fully assembled
fan motor with fan blade and mounting bracket.
2. MATERIAL SUPPLIED (SEE TABLE 1.)
Table 1 lists the contents of this kit and a description of each component.
3. FAN REPLACEMENT
1. Tag and disconnect fan wires.
2. Remove fan assembly 148-0026 from unit by removing two (2) screws Kepco P/N 101-0132 (8-16 x 3/4.ST, THPH)
(save hardware for reassembly).
3. Install fan assembly from this kit using hardware saved from step 2.
4. Connect fan wires as noted during step 1.
TABLE 1. MATERIAL SUPPLIED
ITEM DESCRIPTION
KEPCO
PART NO.
QUANTITY
Fan Motor Replaces fan motor, installed on fan mounting bracket 148-0050 1
Fan Mounting Bracket Attaches fan to chassis 128-1864 1
Fan Blade Installed on fan motor shaft 149-0034 1
Instruction Sheet Contains instructions for installing KIT 219-0525 components 228-1623 1
