II. SPECIFICATIONS
Table 3 lists the model parameters unique to a parallel combination of two 1000W BOP Power Supplies. Table 4
lists the general specifications applicable all the parallel combinations listed in Table 3.
Protection - OUT Termination
(Slave)
1 Provides proper termination for the slave connection to the Protection Cable. 195-0108
Protection - IN Termination
(Master)
1 Provides proper termination for the master connection to the Protection Cable. 195-0107
Chassis Ground Cable 1 Connects chassis ground terminals of all units. 118-1272
Ground Cable mounting
hardware
2 sets Each set consists of eight parts, mounted in the following order: No. 10 star
lockwasher P/N 103-0106 (at chassis), No. 10 flat washer P/N 103-0031, No. 10
split lockwasher P/N 103-0033, 10-32X3/8 nut P/N 102-0008, No. 10 flat washer
P/N 103-0031, [lug(s) from ground cable], No. 10 flat washer P/N 103-0031, No.
10 split lockwasher P/N 103-0033, and 10-32X3/8 nut P/N 102-0008. (See
Purpose
at left for
part
numbers)
Instruction
Manual
1 Lists material supplied. 228-1485
Nut 2 Overcomes tight space for output cable connections. After securing bottom
cable to output terminal stud using one nut, additional cables can be oriented
for best layout and secured with separate nut. 102-0046
TABLE 3. MODEL PARAMETERS FOR TWO (2) HIGH POWER BOP 1000 WATT UNITS (PARALLEL)
(2) Identical Models
(Parallel)
d-c Output Range Closed Loop Gain
E
O Max
I
O Max
Voltage Channel
(V/V)
Current Channel
(A/V)
BOP 6-125MG ±6V d-c ±250A d-c 0.6 25.0
BOP 10-75MG ±10V d-c ±150A d-c 1.0 15.0
BOP 20-50MG ±20V d-c ±100A d-c 2.0 10.0
BOP 25-40MG ±25V d-c ±80A d-c 2.5 8.0
BOP 36-28MG ±36V d-c ±56A d-c 3.6 5.6
BOP 50-20MG ±50V d-c ±40A d-c 5.0 4.0
BOP 72-14MG ±72V d-c ±28A d-c 7.2 2.8
BOP 100-10MG ±100V d-c ±20A d-c 10.0 2.0
TABLE 4. GENERAL SPECIFICATIONS FOR TWO (2) IDENTICAL BOP 1000 WATT UNITS (PARALLEL)
SPECIFICATION RATING/DESCRIPTION CONDITION
INPUT CHARACTERISTICS
Current 176 Va-c 19.0A a-c maximum
264 Va-c 13A a-c maximum
Leakage current 7mA a-c 230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
Programming
resolution / accuracy Voltage 14 bits / 0.2% 2% accuracy for Ext Ref Level. Unit gain
adjustable between 0 and E
ONOM
/10 (voltage)
or I
ONOM
/10 (current).
Current 14 bits / 0.5%
Voltage Limit 12 bits / 0.5%
Current Limit 12 bits / 0.5%
Readback
resolution / accuracy Voltage 16 bits / 0.2% main or limit channel
Current 16 bits / 0.5% main or limit channel
TABLE 2. EQUIPMENT SUPPLIED (CONTINUED)
Item Quantity Purpose
Kepco Part
Number
