I N S T R U C T I O N S H E E T
KEPCO
KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000 FAX (718) 767-1102
http://www.kepcopower.com email: [email protected]
An ISO 9001 Company.
CABLE
219-0446
KIT
CABLE KIT NO. 219-0446
BOP 1000W MODELS (3) IN PARALLEL
I.
DESCRIPTION.
This kit contains the cables and terminations required to operate three identical 1000 Watt BOP High Power mod-
els in parallel, effectively multiplying the output current capacity by three. Only identical models may be config-
ured to operate in parallel.
This kit can be used with all 1000W BOP models that have revision levels as shown in Table 1. Earlier models
that have been upgraded to permit multiple unit configurations must include the letter “A” following the revision
number. CAUTION: Failure to install the ground cables supplied can result in damage to the power supply.
Refer to the associated technical manual supplied with the High Power BOP power supply for all instructions
regarding installation and operation of multiple units in parallel.
II.
SPECIFICATIONS
Table 3 lists the model parameters unique to a parallel combination of three identical 1000W BOP Power Sup-
plies. Table 4 lists the general specifications for the parallel combinations listed in Table 3. For specifications not
listed in Table 3, refer to the General Specifications provided in the associated technical manual supplied with
each 1000W BOP power supply
TABLE 1. REVISION LEVELS APPLICABLE TO THIS KIT
MG Model
Revision
Revisions for previously Upgraded
Units (Must include “A”)
GL Model
Revision
BOP 6-125MG
All
All
BOP 10-75MG
5 or higher
3A or 4A
BOP 20-50MG
8 or higher
5A, 6A or 7A
BOP 20-50GL
All
BOP 25-40MG
All
All
BOP 36-28MG
11 or higher
8A, 9A or 10A
BOP 50-20MG
7 or higher
5A or 6A
BOP 50-20GL
All
BOP 72-14MG
7 or higher
6A
BOP 100-10MG
6 or higher
2A or 4A
TABLE 2. EQUIPMENT SUPPLIED
Item
Quantity
Purpose
Kepco P/N
Common power cable, **
(1.5 ft.)
1
Connects the COMMON terminal Master to the COMMON terminal of Slave
#1.
118-1129
Common power cable, **
(3 ft.)
1
Connects the COMMON terminal Master to the COMMON terminal of Slave
#2.
118-1153
Output Power cable,
(1.5 ft.)
1
Connects the OUTPUT terminal of Master to the OUTPUT terminal of Slave
#1.
118-1112
Output Power cable,
(3 ft.)
1
Connects the OUTPUT terminal of Master to the OUTPUT terminal of Slave
#2.
118-1152
Digital Control (Bitbus) Cable,
(3 ft)
1
Provides communication between master and two slaves
118-1148
** For GL units: Unclamp and remove ferrite from cable before installation.
!
