KEPCO, INC. 131-38 SANFORD AVENUE FLUSHING, NY. 11355 U.S.A. TEL (718) 461-7000
FAX (718) 767-1102 email: [email protected]
2
228-1527 REV 3
033012
Digital Control (Bitbus) Cable
(4.5 ft.)
1
Provides communication between master and three slaves.
118-1149
Parallel Control Cable
(1.5 ft.)
3
Provides control signals required for parallel operation.
118-1119
Protection Cable
(1 ft.)
3
Provides interlock protection signals required for multiple unit operation.
118-1126
Master - IN Parallel
Control Termination
1
Provides proper termination for Parallel Control Cable.
195-0109
Protection - OUT Termination
(Slave)
1
Provides proper termination for the slave connection to the Protection
Cable.
195-0108
Protection - IN Termination
(Master)
1
Provides proper termination for the master connection to the Protection
Cable.
195-0107
Chassis Ground Cable
3
Connects chassis ground terminals of all units.
118-1272
Ground Cable mounting hardware
4 sets
Each set consists of eight parts, mounted in the following order: No. 10
star lockwasher P/N 103-0106 (at chassis), No. 10 flat washer P/N 103-
0031, No. 10 split lockwasher P/N 103-0033, 10-32X3/8 nut P/N 102-
0008, No. 10 flat washer P/N 103-0031, [lug(s) from ground cable], No.
10 flat washer P/N 103-0031, No. 10 split lockwasher P/N 103-0033,
and 10-32X3/8 nut P/N 102-0008.
(See
Purpose
at left for
part
numbers)
Nut
2
Overcomes tight space for output cable connections. After securing bot-
tom cable to output terminal stud using one nut, additional cables can
be oriented for best layout and secured with separate nut.
102-0046
Instruction Manual
1
Lists material supplied and specifications for multiple unit combination.
228-1527
TABLE 3. MODEL PARAMETERS FOR FOUR (4) IDENTICAL BOP 1000 WATT UNITS (PARALLEL)
(4) Identical Models
(Parallel)
d-c Output Range
Closed Loop Gain
E
O Max
I
O Max
Voltage Channel
(V/V)
Current Channel
(A/V)
BOP 6-125MG
±6V d-c
±500A d-c
0.6
50.0
BOP 10-75MG
±10V d-c
±300A d-c
1.0
30.0
BOP 20-50MG
±20V d-c
±200A d-c
2.0
20.0
BOP 25-40MG
±25V d-c
±160A d-c
2.5
16.0
BOP 36-28MG
±36V d-c
±112A d-c
3.6
11.2
BOP 50-20MG
±50V d-c
±80A d-c
5.0
8.0
BOP 72-14MG
±72V d-c
±56A d-c
7.2
5.6
BOP 100-10MG
±100V d-c
±40A d-c
10.0
4.0
TABLE 4. GENERAL SPECIFICATIONS FOR FOUR (4) IDENTICAL BOP 1000 WATT UNITS (PARALLEL)
SPECIFICATION
RATING/DESCRIPTION
CONDITION
INPUT CHARACTERISTICS
Current 176
Va-c
36.0A
a-c
maximum
264 Va-c
25.6A a-c
maximum
Leakage current
14mA a-c
230V a-c, 47-63 Hz
OUTPUT CHARACTERISTICS
Programming
resolution / accuracy
Voltage
14 bits / 0.2%
2% accuracy for Ext Ref Level. Unit gain
adjustable between 0 and E
ONOM
/10 (voltage)
or I
ONOM
/10 (current).
Current
14 bits / 0.5%
Voltage Limit
12 bits / 0.5%
Current Limit
12 bits / 0.5%
Readback
resolution / accuracy
Voltage
16 bits / 0.2%
main or limit channel
Current
16 bits / 0.5%
main or limit channel
TABLE 2. EQUIPMENT SUPPLIED (CONTINUED)
Item
Quantity
Purpose
Kepco Part
Number
