CABLE
219-0406
KIT
CABLE KIT NO. 219-0406
DESCRIPTION. This cable kit provides a-c input and d-c output terminations for the Kepco Model JBW 10W and
15W Series switching power supplies. The kit consists of two cables, one meter long, each having the power supply
mating connectors wired to one end, and unterminated wires at the other end (see Figure 1).
FIGURE 1. CABLE KIT INSTALLATION
