III — SPECIFICATIONS
The following specifications apply to all HSF-1UR 50 Watt
Series models (also refer to Table 1) except where noted.
Other models are also available; consult your Kepco repre-
sentative for their specifications.
INPUT:
Voltage: 120V a-c/240V a-c nominal; Range 95-264V
a-c; 125-370V d-c. (polarity insensitive; consult
factory)
Frequency: Nominal 50-60 Hz; Range 47-440Hz (at
440Hz leakage current exceeds UL/VDE safety
spec.limit).
Current (nominal output at rated load):
-1UR:
1.0A a-c typ., 1.2A a-c max (120V a-c rms input);
0.5A a-c typ., 0.7A a-c max. (240V a-c rms input)
Options T, C, X and Y, all except 3.3V model:
0.7A rms max. (100-120 Va-c input);
0.4A rms max. (200-240 Va-c input).
Options T, C, X and Y, 3.3V model:
0.6A rms max. (100-120 Va-c input);
0.3A rms max. (200-240 Va-c input).
Initial Turn-on Surge: (one-half of first input cycle):
@120V a-c rms, 45A max.,
@240V a-c rms, 90A max.
Brownout Voltage: 85V a-c, 110V d-c
Switching Frequency: 120KHz typical, nominal load
STABILIZATION:
Source Effect: Range 95-132V a-c or
190-265V a-c, 0.2% typ.; 0.3% max.
Load Effect: Range 10%-100% load, 0.5% typ.; 1.5%
max.
Temperature Effect: Range 0 o to 40 o C, 0.5% typ.;
1.0% max.
Combined Effect: 0.9% typ.; 1.8% max. (includes
source, load, and temperature effects).
Time Effect: 0.2% typ.; 0.5% max. (1/2 hr-8 hr at
25
o
C).
RECOVERY CHARACTERISTICS: A step load
change from 50% to 100% produces less than +4% output
excursion. Recovery occurs to within +1% of the original
setting in <2 ms (load change t
r
or t
f
equal to or greater
than 50 µsec).
START-UP TIME: 500 ms. maximum.
HOLDUP TIME:
-1UR: 20 ms. typ. (120V a-c), 15 ms. min (100V a-c);
Options T, C, X and Y, all except 3.3V and 28V mod-
els: 30ms typ. (20ms min.);
Options T, C, X and Y, 3.3V model:
55ms typ., 40ms min.;
Options T, C, X and Y, 28V model:
35ms typ., 25ms min.
DIELECTRIC STRENGTH:
Between input and output: 2KV a-c (3KV a-c for
Options T, C, X and Y) for one minute.
Between input and output with Y-capacitor removed:
3.75KV a-c for one minute.
Between input and case (ground): 2KV a-c for one
minute.
INSULATION RESISTANCE: Between input and
ground, output and ground, input and output;
100 Megohms min. (500V d-c).
LEAKAGE CURRENT
-1UR Models:
UL method, 120V a-c: 0.5 mA maximum;
VDE method, 240V a-c: 0.75 mA maximum.
Options T, C, X and Y:
120V a-c and 60 Hz (in conformance with Den-An):
0.28mA typ, 0.45mA max;
240V d-c and 60 Hz (in conformance with IEC 950
and UL1950)0.38mA typ, 0.6mA max.
SAFETY: UL 60950-1, 1st Edition, 2007-10-31; CSA
C22.2 No. 60950-1-03, 1st Edition, 2006-07; EN 60950.
Units are CE marked per the Low Voltage Directive (LVD),
73/23/EEC and 93/68/EEC. [The standards do not apply
with DC input operation]
EMI: Designed to meet FCC Class B (100-120V a-c) and
VDE 0871 Class B (220-240V a-c).
VIBRATION: (non-operating, one hour on each one of
the three axes): 5-10 Hz, 10 mm amplitude, 10-55
Hz, 2g acceleration.
SHOCK: (non-operating, one-half sinusoidal pulse, three
shocks to each axis): Acceleration: 20g, Duration:
11ms +5ms
OPERATING TEMPERATURE: See Figure 5.
STORAGE TEMPERATURE: -40 o C to +75 o C.
OPERATING AND STORAGE RELATIVE
HUMIDITY: up to 95% (wet bulb temp. <35 o C non-con-
densing).
