DESCRIPTION. The Kepco Model CA 33-R RoHS-compliant Cover (see Figure 1) is supplied for use with Kepco
Series RKW 30 Watt power supplies. The cover is installed by first removing two screws (M3 X 8) from the RKW power
supply (see Figure 1). Then slide the cover onto the power supply, matching the tabs as shown in Detail A, and secure
with screws previously removed. This screw must not be overtightened (max. torque 10 in.- lbs (1.1 N x m).
FIGURE 1. CA 33-R COVER INSTALLATION
COVER TAB
SEE DETAIL A
RKW TAB
3042593-1
SEE DETAIL A
RKW 30W POWER SUPPLY
DETAIL A
RKW TAB
REMOVE EXISTING SCREWS (M3 x 8) FROM
RKW POWER SUPPLY AND USE TO SECURE
COVER TO POWER SUPPLY.
MAX TORQUE 10 1N.-LBS (1.1N x m)
CA 33 COVER
COVER TAB
