KEPCO CA 33 - Manual (Page 2)

2
228-1473 REV 1 071905
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
FIGURE 2. CA 33 OUTLINE DIMENSIONS
0.20 (5.08)
0.45 (11.43) TYP.
0.22
(5.59)
0.40
0.16
(4.06)
0.226 ±0.015 (5.74 ±0.381)
3042641
NOTES:
1. MATERIAL: 0.024 (0.6)
GALVANIZED STEEL.
2. DIMENSIONS ARE IN INCHES,
DIMENSIONS IN
PARENTHESES ARE IN
MILLIMETERS.
3. TOLERANCES: ±0.04 (±1)
UNLESS OTHERWISE
SPECIFIED.
4.32 (109.73)
0.575 ±0.015 (14.60 ±0.381)
1.205 ±0.015
(30.61 ±0.381)
4.500 ±0.015 (114.3 ±0.381)
4.720 ±0.015 (119.89 ±0.381)
0.136
(3.45)
0.136
(3.45)
0.374 ±0.015 (9.5 ±0.381)
1.08
(27.43)
(59.97
2.925 ±0.015
(74.30 ±0.381)
±0.381)
±0.015
2.361
0.275 (6.99) TYP.
0.137 (3.48) TYP.
4.880 ±0.015 (123.952 ±0.381)
3.832 ±0.015 (92.333 ±0.381)
3.497 ±0.015 (88.824 ±0.381)
1.275 ±0.015 (3.2 ±0.381)
0.144 ±0.015 (3.653 ±0.381)
0.144 (3.66)
0.20 (5.08) 0.95
(24.13)
0.377 (9.58)
