6305

IBM PC XT (9 way “D”)

TDX 2

3 TXD (From PC)

RXD 3

2 RXD (To PC)

RTS 4

7 RTS (From PC)

CTS 5

8 CTS (To PC)

DSR 6

6 DSR (To PC)

DCD 8

1 DCD (To PC)

DTR 20

4 DTR (From PC)

GND 7

5 GND

Note the interface cable kit (542 009) can be used to implement the above interconnections.

6.2

Recorder Output

This is available via the 4mm rear panel sockets. The level is proportional to the displayed
reading, depending on the measurement mode:

Transmission

1mV per 0.1%T

Absorbance

1mV per 0.001ABS

Concentration

1mV per concentration unit
