9
SECTION 1 - Introduction
1.1 INSTRUMENT DESCRIPTION
The 6300 and 6320D spectrophotometers are suited to a wide range of applications in education,
quality control, environmental and clinical analysis. Both models are visible spectrophotometers
covering a wavelength range from 320nm to 1000nm, with measurement modes for absorbance,
% transmittance and concentration. These models have full interfacing capability for Analogue
output and serial (RS232) interfacing. The optical system is independently housed and isolated
with lenses to give maximum protection from environmental contamination. Combined with a
mechanically rigid structure, these models provide a system with fast warm-up, low drift and high
reliability.
1.2 INSTRUMENT SPECIFICATION
6300 and 6320D
Wavelength
Range
320 to 1000nm
Resolution 1nm
Accuracy ± 2nm
Spectral bandwidth 8nm
Photometrics
Transmittance
0 to 199.9%
Absorbance -0.300 to 1.999A
Accuracy ±1%T, ±0.01Abs at 1.000 Absorbance
Resolution 0.1%T, 0.001A
Stability 1%/hr after 15 minute warm up
Concentration
Range
-300 to 1999
Resolution 1/0.1
Calibration Blank with a single standard or factor
Units no units, %, ppm, M, g/l, mg/l
Factor 0.1 to 9999
Standard 0.1 to 1999
Other
Beam height
15mm
Light source Tungsten halogen lamp
Outputs Analogue, RS232
Power <50W
Size (w x d x h) 365 x 272 x 160mm
Weight 6kg
