Page 7: 1 strobe
Model AV1-N4X
3.0 Specifications
3.1 Strobe
Specifications:
Voltage:
12VDC, 24VDC,
50/60HZ
120VAC
50/60HZ,
240VAC
50/60HZ
(See specifications label for voltage rating)
Mount:
1/2"
Pipe
Operating Current:
0.44 Amps at 12VDC,
0.22 Amps at 24VDC,
0.10 Amps at 120VAC,
0.07 Amps at 240VAC
Dome Colors:
Amber, Blue, Clear, Green, Red, and Magenta
Operating Temperature:
-31°F to 150°F
Light Source/Lamp Style:
Strobe Tube
Lamp
Life:
7,000
Hours
Candle Power Peak:
175,000
Flash Rate/Minute:
60-80
Joules per Flash:
1.75
Intensity Candela:
40 Amber, 20 Blue, 50 Clear, 20 Green, and 10 Red
Enclosure Rating:
Type 4
Approvals:
UL Listed, CSA Certified, and CE Pending
Dimensions:
5"H x 3"Diameter
Warranty:
1
Year
AV1-N4X Instruction Manual
Rev. 1.1
Page 3 of 6
