Detcon Model 971-041170-00K
Gas Detection System For Highly Corrosive Gases
Operator's Instruction Manual
Deceember 4, 2009 Document #3525 Rev 0.0
Detcon Model 971-041170-00K gas detection system consists of 2 major assemblies:
1. The NEMA 4 fiberglass sample draw enclosure.
2. The remote mount gas sensor assembly.
The NEMA 4 fiberglass sample draw enclosure is detailed in section 1 of this manual. The remote mount gas sensor
assembly is detailed in the attached sensor manual.
detcon inc.
0
100
200
300
400
500
detcon inc. HOUSTON, TEXAS
SAMPLE DRAW
GAS DETECTION SYSTEM
SET
FLOW
CAL
IN
CL OSE
O P E N
SAMPLE
VALVE
CL OSE
O P E N
VENT
ON/OFF
FLOW FAULT
POWER
