CABINET PARTS
Table Top (1)
P/N: TT-1531
Side Panel (2)
TOP
P/N: SP-1531/HL
TOP
Back Panel (1)
P/N: BP-1531
Drawer Side Left (1)
P/N: DS-1524/L
Drawer Side Right (1)
P/N: DS-1524/R
Drawer Bottom (1)
P/N: DB-1531
Drawer Front (1)
P/N: DF-1531
Drawer Back (1)
P/N: DBK-1531
Drawer Dowel (1)
P/N: DDL-1531
Left Door (1)
P/N: DOR-22 1/4L-1531
Right Door (1)
P/N: DOR-22 1/4R-1531
Door Spacer (1)
P/N: DOR-21 9/16-1531
Bottom Shelf (1)
P/N: BS-1531
Middle Shelf (1)
EDGE BANDING
GOES OUT
P/N: MS-1531
Bottom Brace (1)
P/N: B-17 1/2-BF-1531
Top Brace (1)
P/N: B-17 1/2-TF-1531
Table Top Stick (2)
P/N: TTS-1531
Side Splash (2)
P/N: BS-6-1531
Side Splash (2)
P/N: BS-6-1531
Back Splash (1)
P/N: BSP-1531
Knife Rack Side (2)
P/N KR-SIDE-1531
Knife Rack Face (1)
P/N KR-1531
TT
P1 P2
D3
D4
D5
DL DR MS BS
S2
S1
TB
BB
D7
TTS
KR1
KR2
D1
D2
D6
