Category Entry Description Data
Type Range
Channel The channel number. It displays
Group/Port format. Port 2 in
group 1 will be shown as 1/2 RO Two groups
and 4 ports
for each
group
I/F Type Shows the port interface type. RO FXS, FXO
Operating
Status Shows the operation status of
this port. Enable/Disable RO Enable
Disable
T.38 Whether or not this port is
configured to support the T.38
Fax relay RO Enable
Disable
Input Gain Shows the currently configured
input gain
RO -6 db to 6 db
Summary
Output
Gain Shows the currently configured
output gain RO -6 db to 6 db
62
