4.4 Channel Management
Channel numbers and naming: There are up to 16 channels that PBX gateway can support and the
minimum port density is two. For large port number series, the port naming is given in 4 ports a group.
For 7-inches series, the port naming are given as its sequence.
19-inches and 12 inches models
Sequence Name Sequence Name
port 1
1/1
port 11
3/1
port 2
1/2
port 12
3/2
port 3
1/3
port 13
3/3
port 4
1/4
port 14
3/4
port 5
2/1
port 15
4/1
port 6
2/2
port 16
4/2
port 7
2/3
port 17
4/3
port 8
2/4
port 18
4/4
7-inches model
Sequence Name
port 1
1
port 2
2
port 3
3
port 4
4
4.4.1 Summary
