SPECIFICATIONS
ORDERING INFORMATION
Pressure Connections
1/4NPT male, 1/4BSP male, M20X1.5 male (≤15,000
psi)
1/4HP female or 1/4HP male (>15,000 psi)
1/4HP female: Autoclave F-250-C, 9/16" - 18 UNF-2B
1/4HP male: Autoclave M-250-C, 9/16" - 18 UNF-2A
0.236 inch (Ø6mm) test hose (for differential pressure)
Other connections available per request
Electrical Connection
0.156 inch (Ø4mm) sockets
Over Pressure Warning: 120%
Data Logger
Storage capacity: 30 files, 40 records per file
Mode: manual and automatic
Hourly-record: record the data every hour
Interval-record: set by user
Model Number
Model
Accuracy:
02-0.025% of full scale
05-0.05% of full scale
10-0.1% of full scale
Range type:
PSI-range by psi
BAR-range by bar
H
2
O-range by inH
2
O
Pressure port type:
N-1/4NPT male
N2-1/2NPT male
B-1/4BSP male
M-M20X1.5 male
AF-Autoclave F-250-C female
AM-Autoclave M-250-C male
Pressure range P/N:
See pressure range table
Power
Battery: Rechargeable Li-ion polymer battery
Li-Battery working time: 40 hours
Recharge time: 4 hours
External power: 110V/220V power adapter (DC10V)
Enclosure
Case material: Aluminum alloy
Wetted parts: 316L SS
Dimension: Ø120mm X 46mm depth X 184mm height
Weight: 0.7kg
European Compliance: CE marked
Communication
RS232 (DB9/F, environmentally sealed)
Baud rate: 1200,2400,4800,9600
Data length: 8 bits
Stop bit: 2 bits
Address: from 1 to 112
Warranty:1 year
Accessories included
110V/220V external power adapter (DC 10V)
2 pieces 1.5-meter test leads
2 pieces 0.236 inch (Ø6 mm) test hose
(for differential pressure gauge only)
Additel/Land software
(free download at www.additel.com)
Manual
NIST traceable calibration certificate
Optional Accessories
Model
number
Description
9702 Spare rechargeable Li-ion polymer battery for 672
9814
Spare 110V/220V external power adapter (DC 10V)
for 672 digital pressure calibrator
9502
Additel/Log II real time data logging and graphical
software for 681 and 672
9506 Additel/PCal pressure calibration software
9050 USB to RS232 (DB9/M) Adapter
9900-672 Carrying Case for one 672 digital pressure gauge
9021 Spare 2 pieces test leads (1.5-meter) for 672
ADT672 GP300 PSI 02 N
Digital Pressure Calibrators
Additel 672
