WEN 4205 8 inch Drill Press with Laser - Manual (Page 23)

23
Parts list
Item # Stock # Description Qty Item # Stock # Description Qty
1 4205-001 Base 1 34 4205-034 Rubber washer 1
2 4205-002 Column holder 1 35 4205-035 Spindle 1
3 4205-003 Column 1 36 4205-036 Ball bearing 1
4 4205-004 Bolt 3 37 4205-037 Ball bearing 1
5 4205-005 Table bracket 1 38 4205-038 Retain ring 1
6 4205-006 Set screw 1 39 4205-039 Retain ring 1
7 4205-007 Nut 1 40 4205-040 Driving sleeve 1
8 4205-008 Set ring 1 41 4205-041 Ball bearing 2
9 4205-009 Bolt set 1 43 4205-043 Pulley set nut 1
10 4205-010 Lock nut 2 44 4205-044 Spindle pulley 1
11 4205-011 Scale point 1 45 4205-045 Chuck 1
12 4205-012 Bevel lock bolt 1 46 4205-046 Motor 1
13 4205-013 Angle scale 1 47 4205-047 Motor wire 1
14 4205-014 Set screw 2 48 4205-048 Bolt 4
15 4205-015 Table lock handle 1 49 4205-049 Washer 4
16 4205-016 Table 1 50 4205-050 Nut 4
17 4205-017 Housing 1 51 4205-051 Motor pulley 1
18 4205-018 Set screw 2 52 4205-052 Key 1
19 4205-019 Spring 1 53 4205-053 Set screw 2
20 4205-020 Slide bar 1 54 4205-054 Wire insulator 2
21 4205-021 Lock knob 1 55 4205-055 Power cord 1
22 4205-022 Motor base 1 56 4205-056 Switch 1
23 4205-023 Washer 2 57 4205-057 Switch cover 1
24 4205-024 Bolt 2 58 4205-058 Set screw 3
25 4205-025 Feed hub 1 59 4205-059 Pulley cover 1
26 4205-026 Handle bar 3 60 4205-060 Flat screw 1
27 4205-027 Handle knob 3 61 4205-061 V-belt 1
28 4205-028 Coil spring 1 62 4205-062 Chuck key 1
29 4205-029 Spring cover 1 63 4205-063 Label 1
30 4205-030 Nut 1 64 4205-064 Speed label 1
31 4205-031 Quill set screw 1 65 4205-065 Drive screw 4
32 4205-032 Nut 1 66 4205-066 Nut 1
33 4205-033 Quill 1 67 4205-067 Nut 2
