WEN 3920 16 inch scroll saw - Manual (Page 22)

22
Exploded view & parts list (continued)
Item Stock# DESCRIPTION Qty Item Stock# DESCRIPTION Qty
1 90223-001 SCREW ST4.2X9.5 2 46 90223-046 SCREW M4X16 4
2 90223-002 POWER CORD 1 47 90223-047 HOLDER PLATE 1
3 90223-003 SPRING WASHER 6 8 48 90223-048 LOCALIZER 1
4 90223-004 NUT M6 6 49 90223-049 WASHER 6 1
5 90223-005 SCREW M5X10 4 50 90223-050 SWITCH COVER 1
6 90223-006 PLATE COVER 1 51 90223-051 MOTOR 1
7 90223-007 SPRING WASHER 8 2 52 90223-052 ECCENTRIC 1
8 90223-008 SCREW M8X25 2 53 90223-053 TABLE 1
9 90223-009 BASE 1 54 90223-054 BOLT M6X35 1
10 90223-010 SCREW M6X16 4 55 90223-055 HOSE 1
11a 90223-011a HOUSING (LEFT) 1 56 90223-056 SUPPORT ROD 1
11b 90223-011b HOUSING (RIGHT) 1 57 90223-057 AIR BAG SEAL 1
12 90223-012 SUPPORT TABLE 1 58 90223-058 AIR BAG 1
13 90223-013 INDICATOR 1 59 90223-059 WASHER 4 2
14 90223-014 SCREW M6X12 1 60 90223-060 SCREW M8X8 1
15 90223-015 BRACKET 1 61 90223-061 SCREW ST4.2X8 6
16 90223-016 SPRING WASHER 5 9 62 90223-062 NUT M10 1
17 90223-017 SPRING 1 63 90223-063 PCB 1
18 90223-018 FLAT WASHER 6 4 64 90223-064 SCREW M4X8 1
19 90223-019 BOLT M6X40 1 65 90223-065 SCREW M5X35 5
20 90223-020 SPRING 1 66 90223-066 SCREW M5X30 3
21 90223-021 BOLT TENSION 1 67 90223-067 BLOWER TUBE 1
22 90223-022 ROCKER ARM ASSY 2 68 90223-068 KNOB 1
23 90223-023 SPRING WASHER 4 6 69 90223-069 BEARING FENCE 1
24 90223-024 BOLT M4X10 2 70 90223-070 SET PLATE 1
25 90223-025 BEARING FLANGE 4 71 90223-071 SWITCH CASE 1
26 90223-026 SCREW M5X 6 1 72 90223-072 POWER SWITCH 1
27 90223-027 SCREW M6X25 4 73 90223-073 RUBBER FOOT 4
28 90223-028 RETAINER 2 74 90223-074 SCREW ST4.2X13 6
29 90223-029 NUT M5 1 75 90223-075 BACK PLATE COVER 1
30 90223-030 NUT M5 1 76 90223-076 WRENCH 1
31 90223-031 BOLT M5X20 1 77 90223-077 SCREW M4X20 2
32 90223-032 BEARING 625-2Z 2 78 90223-078 BEARING COVER 4
33 90223-033 WASHER 1 79 90223-079 WASHER 5 1
34 90223-034 LINK ASSEMBLY 1 80 90223-080 SCREW M5X8 5
35 90223-035 ALLEN WRENCH 4 1 81 90223-081 SPEED KNOB 1
36 90223-036 CORD CLAMP 1 82 90223-082 SPEED CONTROLLER 1
37 90223-037 BLADE HOLDER 2 83 90223-083 CARBON BRUSH 2
38 90223-038 BOLT M5X25 1 84 90223-084 BRUSH CAP 2
39 90223-039 FLAT WASHER 4 4 85 90223-085 WASHER M10 1
40 90223-040 PLATE CHIP 2 86 90223-086 BLADE STORAGE 1
42 90223-042 BOLT M4X16 2 87 90223-087 WASHER M5 1
43 90223-043 TABLE INSERT 1 88 90223-088 BOLT M5x10 1
44 90223-044 KNOB 1 89 90223-089 LIGHT BASE 1
45 90223-045 BLADE 1 90 90223-090 LIGHT ASSEMBLY 1
