2
Table of contents
Technical data………………………………………………………… 2
General safety rules…………………………………………………… 3
Specific safety rules for the scroll saw……………………………….. 5
Electrical information………………………………………………… 7
Know your scroll saw………………………………………………… 9
Assembly and adjustments…………………………………………… 10
Operation……………………………………………………………... 16
Maintenance………………………………………………………….. 20
Exploded view & parts list...………………………………………….
21
Warranty……………………………………………………………… 23
Technical data
16"
Scroll Saw
Item: 3920
Motor: 120 VAC, 60 Hz, 1.2 A
Speed: 400-1600 SPM (no load)
Throat depth: 16"
Blade: 5" pinned & pin-less
Blade stroke: 9/16"
Cutting capacity: 2" at 90º
Table tilt: 0º to 45º left
Overall dimensions: 26-3/8" x 13" x 14-3/8"
Weight: 33 lb
