WEN 3914 14 inch band saw - Manual (Page 23)

Item # Stock # Description Item # Stock # Description
1 3914-101 Lower Door Assembly 28 3914-128 Wing Nut
2 3914-102 Upper Door Assembly 29 3914-129 Flat Washer
3 3914-103 Retaining Ring 30 3914-130 Hex Head Bolt
4 3914-104 Upper Wheel Shaft 31 3914-131 Locking Knob
5 3914-105 Tension Block 32 3914-132 Socket Head Bolt
6 3914-106 Flange Nut 33 3914-133 Motor
7 3914-107 Guide Plate 34 3914-134 Set Screw
8 3914-108 Nut 35 3914-135 Motor Pulley
9 3914-109 Spring 36 3914-136 Lower Wheel Shaft
10 3914-110 Shaft 37 3914-137 Dust Port
11 3914-111 Retaining Ring 38 3914-138 Shaft
12 3914-112 Tension Bracket Frame 39 3914-139 Collar
13 3914-113 Push Stick 40 3914-140 Handwheel Assembly
14 3914-114 Hook 41 3914-141 Hex Head Bolt
15 3914-115 Hex Nut 42 3914-142 Switch Assembly
16 3914-116 Cap 43 3914-143 Bearing 6202zz
17 3914-117 Tension Knob 44 3914-144 Upper Wheel
18 3914-118 Jam Nut 45 3914-145 Brush Assembly
19 3914-119 Threaded Rod 46 3914-146 Belt Tension Drum Assembly
20 3914-120 Bushing 47 3914-147 Lock Washer
21 3914-121 Tension Release Handle 48 3914-148 Drive Pulley
22 3914-122 Hex Nut 49 3914-149 Lower Wheel
23 3914-123 Spacer 50 3914-150 Socket Head Bolt
24 3914-124 Cam 51 3914-151 Tire
25 3914-125 Hex Head Bolt 52 3914-152 Drive Belt
26 3914-126 Flat Washer 53 3914-153 Blade
27 3914-127 Tracking Knob 54 3914-154 Capacitor
23
