Accurate, Affordable, and Easy To Use
Spectra Precision DET-2 Theodolite
© 2009, Trimble Navigation Limited. All rights reserved. Trimble, the Globe & Triangle logo and Spectra Precision are
trademarks of Trimble Navigation Limited, registered in the United States Patent and Trademark office and in other countries.
All other trademarks are the property of their respective owners.
PN 022507-106A (07/09)
www.trimble.com/spectra
DET-2 Features and Benefits
• 2” angular accuracy - accurate enough for any
construction job, yet the display resolution can
be tailored to any operator’s preferences for fast
readings
• Vertical axis compensation - tilt sensor provides
the highest level of accuracy and can be turned
on or off depending on job requirements
• Dual LCD with large characters - easy to see
angle readings eliminate errors and reduces eye
fatigue
• Back-lit LCD and telescope reticle - allows work
in low light conditions including indoors and
extended hours near dawn and dusk
• Simple six button keypad - quick setups and
simple operation with low operator learning curve
• Large suite of programmable settings - provide
multiple options for various users and job
requirements including zero position of vertical
angle
• Measurement units in degrees, gon, or mils
• 90 degree angle audible notification - for quick
turning and set out of right angles
• Instant conversion of vertical angles to percent of
grade - convenient for slope work and when used
in conjunction with DialGrade ® pipe work.
• NiMH rechargeable battery pack and charger -
lower operating cost with reusable batteries
• Alkaline battery pack standard - provides backup
and eliminates downtime if the charge is lost in
the middle of a job
• Battery status indicator - no power surprises and
allows for better planning
• Automatic shutoff - conserves battery life when
not in use - can be disabled if desired
• IP54 environmental rating - dust and water
resistance withstands the tough conditions of
the construction environment
DET-2 Specifications
Telescope
Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Erect
Magnification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30x
Aperture. . . . . . . . . . . . . . . . . . . . . . . . . . 45 mm (1.7 in)
Focus Distance . . . . . . . . . . . 1.35 m to ∞ (4.43 ft) to ∞
Field of View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1˚ 30’
Stadia Ratio / Constant . . . . . . . . . . . . . . . . . . . .100 / 0
Optical Plummet
Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Erect
Magnification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3X
Angle of view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5˚
Focusing range . . . . . . . . . . . . . . 0.5 m ~ ∞ (1.6 ft ~ ∞)
Reticle type . . . . . . . . . . . . . . . . . . . . . . . . . . . Crosshair
Angle Measuring System
Minimum Reading . . . . . . . . . . . . . . . . . . . . . . .1” or 5”
Precision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2”
Units . . . . . . . . . . . . . . . . . . . . . . . Deg / mil / gon / V %
Display . . . . . . . . Dual, Large Character, Backlit LCD
Tilt Sensor
Automatic Compensation . . . . . . . . . . . . . . ±3’ Range
User set On/Off
Vials
Tubular . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30”/2 mm
Circular . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8’/2 mm
One Touch Button Functions
ON / OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Power
☼ . . . . . . . . . . . . . . . Backlight / Illumination On / Off
HOLD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Angle Hold
R/L . . . . . . Clockwise/Counterclockwise Measurement
0SET . . . . . . . . . . . . . . Zero Reset of Horizontal Angle
V%. . . . . . . . . . . Convert Vertical Degrees to Percent
Dust/Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP-54
Operating Temperature . . . . . . . . . . . . –20°C to +50°C
(–4°F to 122°F )
Size - Instrument . . . . . . . . . . . . . . 164 x 154 x 340 mm
(6.4 x 6.1 x 13.4 in)
Weight - Instrument . . . . . . . . . . . . . . . . 4.5 kg (9.9 lb)
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Year
Each DET-2 comes equipped with a plumb bob,
NiMH rechargeable battery pack and charger,
alkaline battery pack, adjustment tools, rain hood,
multi-language user guide, and hard-shell,
compact, o-ring sealed, carrying case
