Distance Measurement
■ ■
Range with specified prisms
(Good conditions
1 ) with reflector sheet
5 cm x 5 cm ( 2 in x 2 in)
2"
- 1.5 m to 270 m (4.9 ft to 886 ft)
5"
- 1.5 m to 300 m (4.9 ft to 984 ft)
With single prism 6.25 cm (2.5 in)
■ ■
Reflectorless mode 2
2" Good 1 Normal 4 Difficult 5
KGC 3 350 m 250 m 200 m
(18%) (1,148 ft) (800 ft) (656 ft)
KGC 500 m 400 m 250 m
(90%) (1,640 ft) (1,312 ft) (820 ft)
5" Good Normal Difficult
KGC 280 m 250 m 200 m
(18%) (920 ft) (800 ft) (656 ft)
KGC 500 m 500 m 300 m
(90%) (1,640 ft) (1,640 ft) (984 ft)
■ ■
Shortest possible range: 1.5m (4.9 ft)
■ ■
Accuracy 6 (Precise mode) ISO 17123-4
- Prism: ±(2+2 ppm × D) mm
- Reflectorless: ±(3+2 ppm × D) mm
■ ■
Measuring interval 7
Prism Precise Normal
mode mode mode
2"
1.6 sec 0.8 sec
5" 1.4 sec 0.8 sec
Reflectorless Precise Normal
mode mode mode
2" 2.1 sec 1.2 sec
5" 8 1.8 sec 1.0 sec
Least count 1 mm 10 mm
(0.002 ft) (0.02 ft)
Angle Measurement
DIN 18723 accuracy
- horizontal: 2"/0.6 mgon
- vertical: 5"/1.5 mgon
■ ■
Reading system: Absolute encoder
■ ■
Circle diameter: 62 mm (2.4 in)
■ ■
Horizontal/Vertical angle
- 2": Diametrical/Diametrical
- 5": Diametrical/Single
Minimum increment
- Degree: 1/5/10”
- Gon: 0.2/1/2 mgon
- MIL6400: 0.005/0.02/0.05 mil
Telescope
■ ■
Tube length: 125 mm (4.9 in)
■ ■
Image: Erect
■ ■
Magnification:
30Ч (18Ч/36Ч with optional eyepieces)
■ ■
2" Effective diameter of objective:
40 mm (1.6 in)
■ ■
2" EDM diameter: 45 mm (1.8 in)
■ ■
5" Effective diameter of objective:
45 mm (1.8 in)
■ ■
5" EDM diameter: 50 mm (2.0 in)
■ ■
Field of view: 1°20’
■ ■
Resolving power: 3"
■ ■
Minimum focusing distance: 1.5 m (4.9 ft)
■ ■
Laser Pointer: Coaxial Red Light
Tilte Sensor
■ ■
Type: Dual-axis
■ ■
Method: Liquid-electric detection
■ ■
Compensation range: ±3.5'
Communications
■ ■
Communication ports: 1 x serial (RS-232C)
■ ■
Wireless communications:
integrated Bluetooth
Power
Internal Li–ion battery (x2)
■ ■
Output voltage: 3.8 V DC
Operating time 9
■ ■
2"
- approx. 19 hours (continuous distance/
angle measurement)
- approx. 57 hours (distance/angle
measurement every 30 seconds)
- approx. 62 hours (continuous angle
measurement)
■ ■
5"
- approx. 10 hours (continuous distance/
angle measurement)
- approx. 26 hours (distance/angle
measurement every 30 seconds)
- approx. 31 hours (continuous angle
measurement)
Charging time
■ ■
Full charge: 4 hours
General Specifications
Level vials
■ ■
Sensitivity of Circular level vial: 10'/2 mm
Optical plummet
■ ■
Image: Erect
■ ■
Magnification: 3×
■ ■
Field of view: 5°
■ ■
Focusing range: 0.5 m (1.6 ft) to ∞
■ ■
Display face 1: backlit, graphic
LCD (128×64 pixel)
■ ■
Display face 2 (2" only): backlit, graphic
LCD (128×64 pixel)
■ ■
Laser plummet (optional): 4 levels
■ ■
Point memory: 10,000 records
■ ■
Dimensions (W x D x H):
149 mm x 145 mm x 306 mm
(5.8 in x 5.7 in x 12.0 in)
Weight (approx.)
■ ■
2" Main unit (without battery): 3.8 kg (8.4 lb)
■ ■
5" Main unit (without battery): 3.7 kg (8.1 lb)
■ ■
Battery: 0.1 kg (0.2 lb)
■ ■
Carrying case: 2.3 kg (5.1 lb)
Environmental
■ ■
Operating temperature range:
–20 °C to +50 °C (–4 °F to +122 °F)
■ ■
FOCUS 6W: –30 °C to +50 °C
(–22 °F to +122 °F)
■ ■
Storage temperature range:
–25 °C to +60 °C (–13 °F to +140 °F)
■ ■
FOCUS 6W: –30 °C to +60 °C
(–22 °F to +140 °F)
Atmospheric correction
■ ■
Temperature range:
–40 °C to +60 °C (–40 °F to +140 °F)
■ ■
Barometric pressure:
400 mmHg to 999 mmHg/533 hPa to
1,332 hPa/15.8 inHg to 39.3 inHg
■ ■
Dust and water protection: IP66
Certification
■ ■
Class B Part 15 FCC certification,
CE Mark approval.
■ ■
C-Tick.
■ ■
Laser safety IEC60825-1 Ed. 2.0 : 2007
■ ■
2" Reflectorless / Laser Pointer: Class 3R laser
■ ■
2" Prism mode: Class1 laser
■ ■
5" Reflectorless : Class 1 laser
■ ■
5" Laser Pointer: Class 2 laser
■ ■
Laser Plummet (optional): Class 2 laser
■ ■
Bluetooth type approvals are country specific.
(1) Good conditions (good visibility, overcast, twilight, underground,
low ambient light).
(2) Measuring distance may vary depending on targets and
measuring conditions.
(3) Kodak Gray Card, Catalog number E1527795
(4) Normal conditions (normal visibility, object in the shadow,
moderate ambient light).
(5) Difficult conditions (haze, object in direct sunlight,
high ambient light).
(6) ±(3+3 ppm × D) mm –20 °C to –10 °C, +40 °C to +50 °C
(–4 °F to +14 °F, +104 °F to +122 °F)
(7) Measuring time may vary depending on measuring distance
and conditions. For the initial measurement, it may take a few
more seconds.
(8) Measured to KGC 90% at 20 m (65 ft)
(9) Battery life specification at 25 °C (77 °F). Operation time may be
shorter in low temperatures or if the battery is not new.
