GNSS Characteristics
■ ■
45 parallel all-in-view channels
- GPS L1 C/A, L1 P-code, full
wavelength carrier
- GLONASS L1 C/A, full wavelength carrier
- SBAS: WAAS/EGNOS/MSAS/GAGAN
■ ■
Fully independent code and phase
measurements
■ ■
Advanced multipath mitigation
■ ■
Ashtech Z-Blade technology for optimal
performance
■ ■
Up to 20 Hz real-time GPS, GLONASS, SBAS
raw data (code and carrier) and position output
■ ■
Supported data formats: ATOM (Ashtech
Optimized Messaging), RTCM-2.3, RTCM-3.1,
CMR, CMR+, DBEN, LRK
■ ■
NMEA 0183 messages output
■ ■
RTK Network: VRS, FKP, MAC
Accuracy Specifications (HRMS) 1 2 3
Static, Fast Static post-processing
■ ■
Horizontal: 5 mm + 0.5 ppm
■ ■
Vertical: 10 mm + 0.5 ppm
Kinematic post-processing
■ ■
Horizontal: 10 mm + 1 ppm
■ ■
Vertical: 20 mm + 1 ppm
Real-Time Kinematic (RTK)
■ ■
Horizontal: 10 mm + 1 ppm
■ ■
Vertical: 20 mm + 1 ppm
DGPS
■ ■
< 30 cm + 1 ppm typical
SBAS
■ ■
< 50 cm
RTK Initialization (on-the-fly)
Initialization time
■ ■
< 3 min typical (GPS + GLONASS)
■ ■
< 5 min typical (GPS only)
Range
■ ■
Up to 10 km typical, GPS + GLONASS
■ ■
Up to 7 km typical, GPS only
Reliability
■ ■
Up to 99.9% typical
Processor
■ ■
Marvell ® PXA 320
■ ■
Clock frequency: 806 MHz
Operating System
■ ■
Microsoft Windows ® Embedded Handheld 6.5
■ ■
Languages available: English, French,
German, Greek, Italian, Japanese, Korean,
Portuguese, Spanish, Chinese
■ ■
Software package includes:
- GNSS Toolbox for GNSS control
- Internet Explorer
- E-mail client
- Microsoft Office Mobile
- Transcriber (handwriting recognition)
- ActiveSync
Communication
Cellular
■ ■
Built-in GPRS, EDGE class 12
modem Cinterion MC 75i
■ ■
Quad-band 850/900MHz, 1800/1900 MHz
Bluetooth
■ ■
Bluetooth 2.1 (class 2) with DER
■ ■
Profiles: SPP, DUN, FTP, OPP, HSP, A2DP
Other
■ ■
Wireless LAN 802.11b/g (SDIO slot)
Physical Characteristics
Size
■ ■
Receiver: 190x90x43 mm (7.5x3.5x1.7 in)
Weight
■ ■
Receiver only: 0.48 kg (1.06 lb)
■ ■
Receiver with battery: 0.62 kg (1.43 lb)
User Interface
Keyboard
■ ■
Alphanumeric virtual keyboard
■ ■
4-way navigation, OK, menu, escape, zoom
in/out, contextual keys
Display
■ ■
Color TFT High resolution sunlight readable
display with touch screen
■ ■
Size: 3.5” portrait
Memory
■ ■
SDRAM: 256 MB
■ ■
User data storage: 2 GB NAND Flash (non
volatile)
■ ■
SDHC memory card slot
Environmental Characteristics
■ ■
Operating temperature:
-20° to +60°C (-4 to 140°F)
■ ■
Storage temperature:
-25° to +70°C (-13 to 158°F)
■ ■
Waterproof and dust-proof
■ ■
Vibration and Shock: ETS300 019, MIL-
STD-810 method 514.5
■ ■
Free pole drop
Power Characteristics
■ ■
Removable battery: Li-Ion, 6600mAh
■ ■
Battery life: > 8 hrs @ 20 °C with GNSS on 4
■ ■
Charging time: 3 hours
■ ■
External power: 9-28 VDC
Multimedia & Sensors
■ ■
Camera 3M pixels
■ ■
E-Compass
■ ■
G-Sensor
■ ■
Microphone & Speaker
Software / Firmware Options
Firmware options
■ ■
GLONASS
■ ■
GNSS L2 5
■ ■
Fast Output
Software options
■ ■
Spectra Precision Survey Office software
Standard Accessories
■ ■
Integrated stylus
■ ■
Docking station
- Unit charging
- RS232 Interface
- USB Host and Device
- Additional battery charging slot
■ ■
Universal A/C adapter
■ ■
USB data cable
■ ■
ASH-660, L1 GPS/GLONASS antenna
■ ■
Field bracket
■ ■
Antenna vertical extension
■ ■
HI tape
■ ■
Field soft bag
Optional Accessories
■ ■
ASH-661, L1/L2 GNSS antenna 5
(*) Including all available options
(1) Accuracy and initialization specifications may be affected by
atmospheric conditions, signal multipath, satellite geometry and
corrections availability and quality. Position accuracy specifications
are for horizontal positioning. Vertical error is typically < 2 times
horizontal error.
(2) Performance values assume a minimum of five satellites and
following the procedures recommended in the product manual.
High multipath areas, high PDOP values and periods of sever
atmospheric conditions may degrade performance.
(3) Steady state value for baselines < 50 km after sufficient
convergence time.
(4) No BT or WLAN are used, backlight at default setting (50%
brightness), varies with temperature.
(5) Optional upgrade to ProMark 220.
