General
When connected to the data collector:
• 220 Channels for multi-constellation GNSS support
• Integrated transmit/receive UHF radio
• Compact and lightweight design
• RTK, Postprocessed, Kinematic, and Static
• Network RTK positioning
• Integrated wireless Bluetooth ® 2.0 technology
Technical SpecificaTionS
Static GnSS surveying 1
high-accuracy static
Horizontal . . . . . . . . . . . . . . . . . . . 3 mm + 0.1 ppm RMS
Vertical . . . . . . . . . . . . . . . . . . . .3.5 mm + 0.4 ppm RMS
Static & fast Static
Horizontal . . . . . . . . . . . . . . . . . . . 3 mm + 0.5 ppm RMS
Vertical . . . . . . . . . . . . . . . . . . . . . 5 mm + 0.5 ppm RMS
real-Time Kinematic GnSS surveying 1
Horizontal . . . . . . . . . . . . . . . . . . . . 10 mm + 1 ppm RMS
Vertical . . . . . . . . . . . . . . . . . . . . . . 20 mm + 1 ppm RMS
Initialization . . . .Automatic OTF (on-the-fly) while moving
Initialization time . . . . . . . . . . . . . . Typically <10 seconds
Initialization reliability 2 . . . . . . . . . . . . . . Typically >99.9%
Start-up . . . . . <60 seconds from power on to positioning
<30 seconds with recent ephemeris
code differential GpS positioning 1
Horizontal . . . . . . . . . . . . . . . . . . . . 0.25 m + 1 ppm RMS
Vertical . . . . . . . . . . . . . . . . . . . . . . 0.50 m + 1 ppm RMS
SBAS (WAAS/EGNOS/GAGAN/MSAS) differential
positioning accuracy. . . . . . . . .Typically <5 m 3DRMS 3
physical
Dimensions (W×HxD) . . . .19.0 cm x 10.7 cm x 20.0 cm
(7.48 in x 4.21 in x 7.87 in)
Weight (with battery) . . . . . . . . . . . . . . . 1.34 kg (2.95 lb)
Ports
I/O . . . . . . . . . . . . . . . . . . . . . Two 7-pin Lemo, RS-232
Bluetooth
Data Link (UHF radio) antenna . . . . . . . . . . . . . . . TNC
Measurements
• Advanced, sixth generation, custom survey
GNSS technology
• High-precision multiple correlator for GNSS
pseudorange measurements
• Unfiltered, unsmoothed pseudorange measurement
data for low noise, low multipath error, low time domain
correlation and high dynamic response
• Very low noise GNSS carrier phase measurements with
<1 mm precision in a 1 Hz bandwidth
• Proven Spectra Precision low-elevation
tracking technology
• Satellite signals tracked simultaneously:
– GPS: L1/L2/L2C/L5
– GLONASS L1/L2
– BeiDou: B1/B2
– SBAS (WAAS/EGNOS/GAGAN/MSAS): L1C/A, L5
– Galileo: E1/E5A/E5B
environMenTal
Operating temperature . . . . . . . . . . . . . . –40 °C to +60 °C
(–40 °F to +140 °F) 4
–40 °C to +55 °C (–40 °F to +131 °F) 4
with internal radio transmitting
Storage temperature. . . . . . . . . . . . . . . . –40 °C to +75 °C
(–40 °F to +167 °F)
Dust/Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IP66
Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . MIL-STD-810F
Shock/Drop . . . . . . . . . . . . MIL-STD-810F Method 516.5
elecTrical
• Power 10 V DC to 20 V DC external power input with
over-voltage protection on Port 1 and Port 2 (7-pin)
• Rechargeable, 7.4 V 2400 mAh Li-Ion internal battery
• Average operating times on internal battery:
– RTK/Static: 4.0 hours 5
coMMunicaTionS and daTa SToraGe
• Internal post process data storage 64 MB (9 MB
reserved)
• Supports external GSM/GPRS/CDMA modems for point
to point RTK and NTRIP operations
• Internal UHF Transceiver. 1 W or 0.5 W transmit power.
• Supports external UHF transmit data link for RTK base
station operation.
• 1 Hz, 2 Hz, 5 Hz, 10 Hz, and 20 Hz positioning when
configured
6 .
correction formats 7 :
• sCMRx, CMR, CMR+, RTCM 2.1, RTCM 2.2, RTCM
2.3, RTCM 3.0, RTCM 3.1
– 25 KHz and 12.5 KHz channel spacing
• NMEA-0183 output support on COM2 during Network
RTK or autonomous operations
recYclinG inforMaTion
For product recycling instructions and more information,
please go to: www.spectraprecision.com/ev.shtml .
epoch 50 GnSS System
1 Accuracy and reliability may be subject to anomalies due to
multipath, obstructions, satellite geometry, and atmospheric
conditions. The specifications stated recommend the use of stable
mounts in an open sky view, EMI and multipath clean environment,
optimal GNSS constellation configurations, along with the use of
survey practices that are generally accepted for performing the
highest-order surveys for the applicable application including
occupation times appropriate for baseline length. Baselines longer
than 30 km require precise ephemeris and occupations up to 24 hr
may be required to achieve the high accuracy static specification.
2 May be affected by atmospheric conditions, signal
multimath,obstruction, and satellite geometry.Initialization reliabilityis
continuously monitored to ensure the highest quality.
3 Depends on SBAS (WAAS/EGNOS) system performance.
4 Below –20°C, external power must be used.
5 Three batteries supplied standard.
6 When used with Survey Pro, only 1 Hz and 5 Hz modes are
supported.
7 Not all protocols will work with all radio baud rates and channel
spacing.
