Mounting system exploded view, Model # sp-2200 – SnowEx SP-2200 User Manual
Page 23
© Trynex International 2010
1 — 23
Mounting System Exploded View
Model # SP-2200
TRIM SIDE PLATES AS
NEEDED TO ALLOW GATE
TO SWING OPEN.
.
y
t
Q
n
o
it
p
i
r
c
s
e
D
.
o
N
t
r
a
P
y
e
K
2
D5303 Hinge Truck Side
D5309 Hinge Pin
D5308 Salt Shield
D5535 1/2-13 Nylox Nut
D5312 Mounting Strap
D6143 1/2-13 x 1-1/4 Serrated Flange Bolt
10
2
2
2
10
D4135 Hair Pin Clip
1
