1 D5313 Auger Weldment
Auger Drive Assembly Parts Breakdown
Model # SP-2200
D5527 Bearing
D4124 3/8” Nylock Nut
D5305 Transmission Mounting Bracket
D6825 Auger Motor
D5753 Transmission Bracket Mounting Bolt
D6132 1/4-20 x 3/4 SS HH Serrated Flange Bolt
D5706 5/16 Serrated Flange Bolt
D6894 Auger Transmission
D5306 Auger Motor Cover
D4313 Lock Washer
D6133 5/16-18 x 1/2 HH Bolt 2
1
4
2
8
2
4
1
1
2
2
D6842 Auger Motor Coupler 2
Ref Only 3/16 Key Stock 2
T15014 1/4” Flat Washer 2
D5776 Auger Coupler Spyder 1
